Delta, an FAA ODA, specializing in Part 23/25 aircraft certification and engineering services, is now expanding its service offerings to include 3D scanning capabilities.
This new 3D scanning technology allows Delta to scan and model a multitude of parts, equipment and interiors, including avionics and electrical equipment racks, cabin interiors, fuselage sections, and even smaller brackets, hardware and connectors.
Below is an example of an aircraft wingtip modeled using the in-house 3D technology.
- Top Level – Final CAD model of wingtip, available in many formats
- Second Level – Intermediary DX model, showing surface and solid construction
- Third Level – Direct scan output, showing read data
- Bottom Level – Photo of scanned wingtip
